3d model description

A set of rotation indicators i made for testing NEMA17 motors and control systems in the comfort of my desktop before attaching them to the actual bal...l shafts.
The motors i use have a 5mm shaft.
The indicators can be stuck on without any means of fastening, the friction fit is enough to allow the intent use and removal afterwards without any hassle.


3d model print parameters

-...

Tags

Axis Motor Motor test Rotation Rotation indicator Shaft Stepper Stepper motor Xyz Xyz da vinci Robotics

License

CC Atribution
